Easy Tile


Pre-Grouted Tile Panel · MineCore Mineral Core · ASTM E-84 Class A · 100% Inorganic · Waterproof


Back to Prefab Systems
Product Overview

Easy Tile — Pre-Grouted Tile Panel

Carve Easy Tile is a large-format wall panel with a factory-finished tile face — realistic grout lines in matt or glazed surfaces — on a 100% inorganic calcium silicate mineral core. One panel covers dozens of tiles and installs with structural adhesive: no mortar, no on-site grouting, no tile setter. Completely waterproof and Class A fire rated for bathrooms, kitchens, and commercial interiors.

CLASS A
Fire Rating
ASTM E-84
1/3
Lighter Than
Ceramic Tile
100%
Inorganic
PVC & Glue Free
General Specifications

Product Specifications

Core Material Autoclaved calcium silicate board (Tobermorite crystal structure)
Standard Panel Size 1220 × 2440 / 3050 mm (4′ × 8′ / 10′) — available in different sizes per requirements
Custom Panel Sizes 600 / 1050 mm wide × 2440 / 2600 / 2800 mm
DIY Panel Sizes 600 × 1200 mm · 400 × 800 mm · 300 × 600 mm
Profile 8 mm tongue & groove (DIY sizes: 4-side T&G)
Surface Finishes Matt · Glazed (600 mm-wide panels and DIY sizes)
Grout Line U-bevel, factory finished — white, black, or grey grout effect
Tile Face Formats 300 × 600 · 100 × 100 · 75 × 300 mm subway · custom digital prints
Fire Performance

Class A Rated — Withstands 1000°C

Easy Tile meets the highest fire performance standards for interior wall applications in both U.S. and European markets.

ASTM E-84 Class A — Flame Spread Index 10, Smoke Developed Index 20 (Intertek Report No. 201130011SHF-003)
EN 13501-1 (EU): A2-s1, d0 — formaldehyde, heavy metals, VCM passed
Withstands 1000°C over 3 hours without inflaming
No harmful emissions at high temperature
100% inorganic mineral core — no PVC, no glue, no formaldehyde
Easy Tile fire performance
Performance & Certifications

Certified Performance

Waterproof
Completely Waterproof
Stability unaffected even when fully immersed in water. 6-hour boiling test passed.
Weight
1/3 Lighter Than Ceramic
Approximately 1/3 lighter than equivalent ceramic tile coverage — easier to handle and install.
Indoor Air Quality
FloorScore® Certified
SCS-FS-20236 — TVOC ≤ 0.5 mg/m³ per CDPH v1.2-2017. REACH VOC test passed.
Emissions
Formaldehyde Free
No glue added. Formaldehyde free. Cured with water only under high-pressure steam.
Quality Systems
ISO 9001 & 14001 Certified
Manufactured under ISO 9001:2015 quality management and ISO 14001:2015 environmental systems.
Composition
100% Inorganic Core
Silicate sand, calcium powder, cement, and paper pulp. Autoclave-cured forming Tobermorite crystals.
Installation & Handling

No Mortar. No Grouting. No Tile Setter.

One large-format panel covers dozens of tiles and installs with structural adhesive. Panels interlock via tongue-and-groove edges for a clean, fast installation.

Bond to a flat, dry, structurally sound substrate with structural adhesive
Panels interlock via tongue-and-groove edges
Cut and drill with standard carbide woodworking tools — no special equipment
DIY-friendly small-format panels with 4-side T&G for residential renovation
Store flat on a level surface in a dry, covered area
Carry panels vertically on edge
Easy Tile installation
Typical Applications

Where It's Used

Bathroom & Shower Walls
Kitchen Backsplashes
Hotel & Boutique Interiors
Commercial Restrooms & Wet Rooms
Retrofit Over Existing Tile
Healthcare & Education Facilities

Interested in Easy Tile for Your Project?

Tell us about your project and we'll help determine if Easy Tile pre-grouted panels are the right solution for your bathroom, kitchen, or commercial wet area.
