Fiberglass-Core Fire-Rated Compact Board · ASTM E84 Class A
Carve Non-Combustible HPL is a high pressure melamine board built on a fiberglass-reinforced modified phenolic core with aluminium hydroxide flame-retardant filler. It achieves a Flame Spread Index of 0 under ASTM E84 — the best possible result — making it ideal for interior wall and ceiling finishes where Class A fire performance is mandatory.
| Product Name | Carve Non-Combustible High Pressure Melamine Board |
| Core Construction | Modified phenolic (P/F) resin, fiberglass filled, with aluminium hydroxide |
| Surface | Melamine decorative surface |
| Standard Sheet Size | 1220 × 2440 mm (4′ × 8′) — available in different sizes per requirements |
| Standard Thickness | 3 mm (other grades and thicknesses available) |
| Weight | ≈ 10.56 kg/m² at 3 mm (as measured, SGS) |
| Colors / Finishes | Available upon request |
| Physical Properties | Density · wear · scratch · water absorption · flexural strength — test data available upon request |
Tested to ASTM E84-12 by SGS-CSTC Standards Technical Services Co., Ltd. (Report No. AJD201204479). No ignition observed — maximum flame spread 0 ft.
Store flat in a dry, well-ventilated area. Product is stable as supplied; avoid extreme temperatures.
Tell us about your project and we'll help determine if Non-Combustible HPL is the right material for your wall, ceiling, or interior finish application.
